[ER7212PC] Omada Gigabit VPN Router with PoE+ Ports and Controller

TP-Link ER7212PC, Omada 3-in-1 Gigabit VPN Router

• 3-in-1 Router: Integrates router, PoE+ output, and Omada centralized managementability altogether. Up to 10 EAPs can be centrally managed.
• Professional Hardware: Dual-CoreCPU with 1GB DDR3 memory provides stellar performance for up to 12x Gigabit ports.
• Up to 4x WAN Ethernet Ports: Equipped with 2x Gigabit SFP WAN/LAN ports, 1x Gigabit RJ45 WAN port, and 1x Gigabit RJ45 WAN/LAN port.
• 110W PoE Budget: 8x 802.3at/af-compliant PoE+ RJ45 LAN ports yield a total power supply of 110W*.
• Centralised Management: Cloud access and the Omada app offer convenience and easy management.
• Highly Secure VPN: Supports IPsec VPN, OpenVPN, and L2TP/PPTP VPN connections.
• Easy Installation: Fanless and compact design for desktop and wall mounting.
• Learn more about Omada Cloud SDN>?

HARDWARE FEATURES

• Standards and Protocols :• IEEE 802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3z, IEEE 802.3x, IEEE 802.1q
  • TCP/IP, DHCP, ICMP, NAT, PPPoE, NTP, HTTP, HTTPS, DNS, IPSec, PPTP, L2TP, SNMP
• Interface :• 2 Gigabit SFP WAN/LAN ports
  • 1 Gigabit WAN port
  • 1 Gigabit LAN/WAN port
  • 8 Gigabit LAN ports
• Network Media :• 10BASE-T: UTP category 3, 4, 5 cable (Max 100 m)
  EIA/TIA-568 100? STP (Max 100 m)
  • 100BASE-TX: UTP category 5, 5e cable (Max 100 m)
  EIA/TIA-568 100? STP (Max 100 m)
  • 1000BASE-T: UTP category 5, 5e, 6 cable (Max 100 m)
• Fan Quantity :Fanless
• Button :Reset Button
• Power Supply :53.5VDC/2.43A Adapter
• PoE Budget :8 ports PoE+ output, 110 W PoE Budget
• Flash :8Mb Nor + 4 GB EMMC
• DRAM :1 GB DDR3
• LED :PWR, SYS, CLOUD, PoE Max, SFP 1, SFP 2, WAN (Speed, Link/Act), LAN (Speed, Link/Act)
• Dimensions ( W x D x H ) :8.9 x 5.2 x 1.4 in (226 x 131 x 35 mm)
• Protection :4 kV surge protection
• Enclosure :Steel
• Mounting :Desktop/Wall-mount
• Max Power Consumption :• 133.2W with PoE Max
  • 13.88W without PoE

PERFORMANCE

• Concurrent Session :24,980
• New Sessions /Second :1,900
• NAT (Static IP) :935.5 Mbps / 942.1 Mbps
• NAT(DHCP) :940.2 Mbps / 941.7 Mbps
• NAT(PPPoE) :913.1 Mbps / 935.2 Mbps
• NAT (L2TP) :545.0 Mbps / 912.7 Mbps
• NAT (PPTP) :523.0 Mbps / 912.8 Mbps
• IPsec VPN Throughput (AES256) :168.5 Mbps
• IPsec VPN Throughput :AES256: 168.5 Mbps
• OpenVPN :34 Mbps
• L2TP VPN Throughput :• Unencrypted: 845.3 Mbps
  • Encrypted: 333.2 Mbps
• PPTP VPN Throughput :• Unencrypted: 1012.6 Mbps
  • Encrypted: 401.4 Mbps
• 66 Byte Packet forwarding rate :154,069 pps / 156,977 pps
• 1,518 Byte Packet forwarding rate :81,193 pps / 81,193 pps

BASIC FUNCTIONS

• WAN Connection Type :• Static IP
  • Dynamic IP
  • PPPoE
  • PPTP
  • L2TP
• MAC Clone :Modify WAN MAC Address
• DHCP :• DHCP Server
  • DHCP Address Reservation
  • Multi-IP Interfaces
  • Multi-Net DHCP
• IPv6 :support
• VLAN :802.1Q VLAN
• IPTV :IGMP v2/v3 Proxy

ADVANCED FUNCTIONS

• ACL :IP/Port/Protocol/Domain Name Filtering
• Advanced Routing :• Static Routing
  • Policy Routing
• Bandwidth Control :IP/Port-based Bandwidth Control
• Load Balance :• Intelligent Load Balance
  • Application Optimized Routing
  • Link Backup
  • Online Detection
• NAT :• Multi-Net NAT
  • Virtual Server
  • NAT-DMZ
  • FTP/H.323/SIP/IPSec/PPTP ALG
  • UPnP
• Session Limit :IP-based Session Limit

VPN

• SSL VPN :-
• IPsec VPN :• 20 IPSec VPN Tunnels
  • LAN-to-LAN, Client-to-LAN
  • Main, Aggressive Negotiation Mode
  • AES128, AES192, AES256 Encryption Algorithm
  • IKE v1/v2
  • SHA1, SHA2 Authentication Algorithm
  • NAT Traversal (NAT-T)
  • Dead Peer Detection (DPD)
  • Perfect Forward Secrecy (PFS)
• PPTP VPN :• PPTP VPN Server
  • PPTP VPN Client (10)
  • 16 Tunnels
  • PPTP with MPPE Encryption
• L2TP VPN :• L2TP VPN Server
  • L2TP VPN Client (10)
  • 16 Tunnels
  • L2TP over IPSec
• OpenVPN :• OpenVPN Server
  • OpenVPN Client (10)§
  • 16 OpenVPN Tunnels

SECURITY

• Filtering :URL Filtering
• ARP Inspection :-
• Attack Defense :• TCP/UDP/ICMP Flood Defense
  • Block TCP Scan (Stealth FIN/Xmas/Null)
  • Block Ping from WAN
• Access Control :Source/Destination IP Based Access Control

AUTHENTICATION

• Web Authentication :• No Authentication
  • Simple Password
  • Hotspot (Local User / Voucher / SMS / Radius)
  • External Radius Sever
  • External Portal Sever
  • Facebook

MANAGEMENT

• Omada App :Yes
• Centralized Management :Management of up to 2 Omada switches, and 10 Omada access points
• Cloud Access :Yes
• Service :Dynamic DNS (Dyndns, No-IP)
• Maintenance :• Web Management Interface
  • Remote Management
  • Export & Import Configuration
  • SNMP v1/v2c/v3
  • Syslog Support
• Zero-Touch Provisioning :-
• Management Features :• Automatic Device Discovery
  • Intelligent Network Monitoring
  • Abnormal Event Warnings
  • Unified Configuration
  • Reboot Schedule
  • Captive Portal Configuration
  • Management of up to 2 Omada switches and 10 Omada access points

OTHERS

• Certification :CE, FCC, RoHS
• Package Contents :• ER7212PC
  • Power Adapter
  • Power Cord
  • Quick Installation Guide
• System Requirements :• Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7/8/8.1/10
  • MAC OS, NetWare, UNIX or Linux
• Environment :• Operating Temperature: 0 °C to 45 °C (32 °F to 113 °F)
  • Storage Temperature: -40 °C to 70 °C (-40 °F to 158 °F)
  • Operating Humidity: 10% to 90% non-condensing
  • Storage Humidity: 5% to 90% non-condensing
